Curtain wall
Stick built packages: elevations, details of typical and special conditions, and surrounding construction.
Commercial glass & aluminum · Stark City, Missouri
Shop drawings the shop can install from.
Architectural Wall Design prepares curtain wall, storefront, entrance, and custom aluminum packages for glazing contractors and manufacturers. Send the architecturals, specifications, and proposal. Get an estimated hours-based quote.
Built for commercial glazers — not homeowners, not residential plans.
$40 per estimated hour after reviewTravis prices from the architecturals and specs. The set price follows systems, elevations, details, and complexity.
Two markup reviews includedOne structural markup review and one submission markup review, unless the scope changes.
Systems you already buyKawneer, YKK, Manko, Tubelite, CRL, Oldcastle, EFCO, Wausau, Dorma, and similar lines.
Drawn across
KawneerYKKMankoTubeliteCRLOldcastleEFCOWausauDormaand others
Scope
Packages for the systems you bid.
AWD is a contract shop-drawing office for commercial glazing — curtain wall, storefront, entrances, and the details between them. Engineering stamps stay with your engineer. Drafting stays with us.
Storefront & ribbon
Stick built packages: elevations, details of typical and special conditions, and surrounding construction.
Entrances & all-glass
Doors, hardware coordination if hardware is by you the customer. If hardware is not provided please note on quote.
Custom & mixed systems
Sunshades, interior glass, ACM transitions, and jobs that mix manufacturers.
Pricing
Hours after the review. Not a guess from a cover sheet.
The set price depends on systems, elevations, details, and complexity. Travis prices after reviewing architecturals and specs. A quote covers one structural markup review and one submission markup review unless the scope changes.
Shop drawings
$40/ estimated hour
After architecturals and specs are reviewed. Set price depends on systems, elevations, details, and complexity.
Payment
5% off if a check is in hand within 15 days of the invoice. Balance is due in 30 days.
About
Travis Richardson, drawing commercial glass since 1999.
Travis has been drafting aluminum and glass for about 27 years, and taking contract shop-drawing work since 2014 (12 years). Architectural Wall Design is the company that work runs through — a shop-drawing office for glazers and manufacturers, based in Stark City, Missouri.
The point of the set is not a pretty PDF. It is a package your fabricator, installer, and reviewer can use without a second explanation of the job.
- Drafting since
- 1999
- Contract shops since
- 2014
- Quote rate
- $40/hr
- Home shop
- Stark City, MO
Sample work
Sample shop drawings
This is a redacted curtain-wall package Travis approved to publish on the site — not a live client job. Open the PDF in your browser.
PDF · Curtain wall
Next job
Send the set. Get a number you can take to the GC.
Use the questionnaire if you have systems and dates. If the PDFs are huge, email travis.r@awddrafting.com or call (417) 455-6313 and send a link.
